An aluminum bonding lug is mounted directly to the side of the exhaust stack. An aluminum bonding conductor connects from the lug down to a tee connection at the main lightning protection conductor running along the roof. The main conductor is supported by typical aluminum supports anchored to the roof surface. All bonding connections are installed above the exhaust stack flashing.
MAIN CONDUCTOR ALUMINUM SUPPORT, TYPICAL ALUMINUM BONDING LUG ALUMINUM BONDING CONDUCTOR TEE CONNECTION TO MAIN CONDUCTOR ROOF EXHAUST STACK NOTE: BOND ABOVE THE EXHAUST STACK FLASHING.
