Electrical schematic detailing the load bank dump automatic transfer switch connection and ancillary power panel distribution for Data Hall 02 System. The configuration includes a 5000 A 100% rated load bank 02G1LB with cam locks, a 3000 A 100% rated main circuit breaker 02G1MCB, a 3000 A 100% rated main circuit breaker 02G2MCB, and an ATS control data hall 02 system with 2.TSG1 TSCS data connection.
2.TSG1 ATS CONTROL DATA HALL 02 SYSTEM 3000 A 100% RATED 02G2MCB ANCILLARY POWER PANEL TSCS DATA CONNECTION 5000 A 100% RATED 02G1LB LOAD BANK CAM LOCKS LOAD BANK DUMP ATS CONNECTION 3000 A 100% RATED 02G1MCB
