Electrical · E-8VW46

Mezzanine Ground Bar and PDU Grounding Diagram

About this detail

Multiple power distribution units connect to a central mezzanine ground bar using number 4/0 grounding conductors. A 500 kcmil grounding conductor extends from the ground bar.

PDU PDU PDU PDU PDU PDU PDU PDU PH5 - MEZZ GROUND BAR #4/0 G. #4/0 G. 500kcmil G.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
