Electrical · E-8MH3E

Emergency Sludge Loadout Control Panel One-Line Diagram

About this detail

This partial one-line diagram details the electrical connections for the emergency sludge loadout control panel PNL-79192 and PLC-70 I/O drop 2. Connections include a fiber optic cable to PLC-70 I/O drop 3 panel PNL-79218, a connection to PLC-70 I/O drop 1 panel PNL-73706, and a 120V AC power supply from the uninterruptible power supply panel PNL73UPS-9 with two number 12 gauge conductors and one ground in a 1-inch conduit.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
