A light pole mounts onto a concrete base using a base plate secured over leveling nuts. A number ten ground conductor runs from the panel ground bar and connects to the ground lug of the pole inside the handhole. Grout packs all around beneath the base plate, protected by a base cover. Pole base construction details refer to the structural drawings.
REFER TO STRUCTURAL DRAWINGS FOR POLE BASE CONSTRUCTION CONCRET E BASE POLE BASE PLATE #10 GROUND CONDUCTOR TO PANEL GROUND BAR. CONNECT TO GROUND LUG OF POLE POLE HANDHOLE BASECOVER GROUT ALL AROUND LEVEL NUT 5'-0" WHERE POSSIBLE OR CENTERED BETWEEN CURBS. "B" "A"
