Ancillary generator electrical distribution schematic showing 30kVA transformers supplying 100A 120/208V panels including future provisions. Panels G1, G2, and G3 each receive power through individual 30kVA transformers, while panel G4 is designated as future. The diagram specifies 100A, 120/208V ratings across the generator ancillary distribution equipment.
(FUT) G4 PANEL 100A- 120/208 G2 PANEL GEN ANCILLARY G1 PANEL 100A-120/ 208 GEN ANCILLARY G3 PANEL GEN ANCILLARY 100A-120/ 208 100A-120/ 208 30KVA 30KVA 30KVA (FUT) G4 PANEL 100A- 120/208 G2 PANEL GEN ANCILLARY G1 PANEL 100A-120/ 208 GEN ANCILLARY G3 PANEL GEN ANCILLARY 100A-120/ 208 100A-120/ 208 30KVA 30KVA 30KVA 1
