Electrical · E-7PAY9

Classroom Lighting Control Switch Station Details

Elements

About this detail

Low-voltage lighting control switch stations designated as LV8 and LV2 serve classroom and quiet room applications. The eight-button station provides automated and manual control functions including master on and off, dim down and dim up, alongside four preset lighting scenes titled warm, neutral, cool, and focus. A two-button station handles basic all on and all off switching alongside standard low-voltage switch symbols. Accompanying text notes specify compliance requirements under the Washington Energy Code, mandating automatic on at fifty percent light output via ceiling-mounted occupancy sensors, daylight zones, and timeclock-controlled switched receptacle integration during school hours.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
