An electrical panel with a maximum weight of three hundred pounds is surface-mounted to a drywall partition backed by sixteen-gauge steel channels. Unistrut P-1000 channels extend vertically from the floor to the top of the enclosure and are secured with two quarter-inch sheet metal screws at each backing plate. The panel connects to the Unistrut using three-eighths-inch diameter bolts with spring washers at each corner for a total of four bolts.
ELECTRICAL PANEL UNISTRUT P-1000 EXTENDED FROM FLOOR TO TOP OF ENCLOSURE. DRY WALL PER ARCHITECTURAL SECTION A-A A A UNISTRUT 6" TYP 24" 24" ELEVATION 3 BACKING REQUIRED 16 GA BACKING PER 8/S-600 VERTICALLY SPACED AT 24" OC (2) 1/4" SMS AT EA BACKING PLATE 3/8" DIA BOLT W/SPRING WASHER EA CORNER (4 TOTAL) MAX WEIGHT= 300 LBS 15IN MIN 9IN MAX
