A starter and or disconnect switch is mounted to Unistrut P-3000 framing which is securely anchored to the floor with floor plates. Incoming power feeds the equipment from below. A liquid tight flexible conduit connects to the equipment with a maximum length of twenty four inches.
3' - 6" 1. STARTER AND/OR DISCONNECT SWITCH. 2. LIQUID TIGHT FLEX CONDUIT TO EQUIPMENT. MAX LENGTH 24". 3. UNISTRUT SECURELY ANCHORED WITH FLOOR PLATES (TYP). NOTES: 1 UNISTRUT P-3000 2 INCOMING POWER 3 NONE 2 FREE STANDING DISCONNECT SWITCH oQ l \ O
