An underground concrete ductbank encases ten six-inch 12.47kV RMP conductors arranged in two rows within a concrete mass measuring four feet two and one-half inches wide by one foot nine and one-half inches high. Typical edge and interior clearances are three inches. A legend defines the conduit type and size.
4' - 2 1/2" 1' - 9 1/2" 3 1/2" 3" (TYP) 3" (TYP) LEGEND: R = 6" 12.47kV RMP CONDUCTOR R R R R R R R R R
