Conduit and Pipe Ground Ring Bonding Method

About this detail

An electrical conduit or pipe is bonded to a ground conductor utilizing an O-Z/Gedney ground clamp matched to the conduit size. The schedule correlates standard conduit sizes ranging from one-half inch to six inches with specific catalog numbers for the ground clamps. The ground conductor secures directly into the clamp assembly attached around the exterior of the conduit or pipe.
