Electrical · E-5QPGH

IT Room UPS Power Distribution Diagram

About this detail

An uninterrupted power supply rated at twenty kilovolt-amperes receives a four hundred eighty-volt three-phase input and delivers a two hundred eight over one hundred twenty-volt three-phase four-wire output. The system connects downstream to panel EDP2092XLI rated at one hundred amperes, two hundred eight over one hundred twenty volts, three-phase, four-wire with a ten kiloampere interrupting capacity and a seventy-ampere three-pole breaker. Upstream it interfaces with panel EDP2093XHI rated at two hundred twenty-five amperes, four hundred eighty over two hundred seventy-seven volts, three-phase, four-wire with a forty-two kiloampere interrupting capacity and a two hundred twenty-five-ampere three-pole breaker. Circuit designations 008Q5 and 008Q6 are marked along the distribution path.
