An exploded isometric view details the mounting configuration for a Genesis ceiling speaker, model GC-S7. The assembly begins with a standard four-inch square electrical box recessed in the ceiling cavity. A device unit mounts directly to the electrical box using screws through aligned mounting tabs. Finally, a perforated device cover secures over the device unit to complete the installation.
ELECTRICAL STD. 4 SQ. BOX UNIT DEVICE DEVICE COVER
