A push-up slip cable attachment is secured to a supplemental structural steel anchorage channel using a push-up slip cable attachment bracket typically. The assembly incorporates a four millimeter push-up spiral strand three hundred sixteen stainless steel cable with a minimum break load of 2.8 kips, connected via an R2 swaged end fitting. Dimensions indicate a one and one-quarter inch projection from the channel face, a one-inch spacing, and a one-quarter inch by one and one-eighth inch clearance detail. The tie-down slip cable connection is shown indicatively for design intent.
R2 SWAGED END FITTING 4MM PUSH-UP SPIRAL STRAND 316 SS CABLE (MBL = 2.8 KIPS) TYP. 3D AXON VIEW 1 1/4" 1" 1 1/8" 1/4" SUPPLEMENTAL STRUCTURAL STEEL ANCHORAGE CHANNEL, TYP. SUPPLEMENTAL STRUCTURAL STEEL ANCHORAGE CHANNEL, TYP. PUSH-UP SLIP CABLE ATTACHMENT BRACKET, TYP. NOTE: TIE-DOWN SLIP CABLE CONNECTION SHOWN INDICATIVELY FOR DESIGN INTENT. SWAGED END FITTING
