Galvanized rigid steel conduit rises through a pipe sleeve set into the concrete floor slab to feed power to the motor. A flexible metal conduit connects from the rigid conduit up to the motor terminal box using a flexible connector. Side and front elevations illustrate the vertical drop and alignment for equipment connections.
PIPE SLEEVE MOTOR FLEXIBLE CONNECTOR FLEXIBLE METAL CONDUIT GALVANIZED RIGID STEEL CONDUIT SIDE VIEW FRONT VIEW FLEXIBLE METAL CONDUIT FLOOR SLAB
