Electrical · E-5C783

Isolated Ground Receptacle Wiring Detail

About this detail

An isolated ground receptacle with an orange faceplate is wired through a conduit containing phase conductors, a neutral conductor, an equipment ground conductor, and an isolated equipment ground conductor. The isolated equipment ground connects directly to the receptacle without bonding to the receptacle frame. The enclosure is separately bonded to the standard equipment ground conductor. A dedicated isolated ground, equipment ground, and neutral conductor are provided for each circuit serving designated isolated ground receptacles.
