An equipment rack main section mounts against an internal wall utilizing two-by-six wood backing framing. A power junction box installs within the wall assembly behind the rack backbox. The layout maintains thirty-six inches of code-required clearance at the front and back of the enclosure. The swing clearance radius for the rack main section accommodates either right-side or left-side opening configurations.
C PLAN VIEW A 2x6 INTERNAL WALL BACKING. EQUIPMENT RACK BACKBOX. POWER J-BOX. RACK MAIN SECTION. CLEARANCE REQUIRED FOR SWING OF RACK MAIN SECTION MAY BE RIGHT SIDE (AS SHOWN) OR LEFT SIDE. 36" CLEARANCE REQUIRED BY CODE AT FRONT AND BACK OF RACK. 2x6 INTERNAL WALL BACKING. EQUIPMENT RACK BACKBOX. POWER J-BOX. RACK MAIN SECTION. CLEARANCE REQUIRED FOR SWING OF RACK MAIN SECTION MAY BE RIGHT SIDE (AS SHOWN) OR LEFT SIDE. 36" CLEARANCE REQUIRED BY CODE AT FRONT AND BACK OF RACK.
