An electrical panel is mounted using four one-and-five-eighths-inch by one-and-five-eighths-inch by twelve-gauge Unistrut channels typically positioned horizontally at the upper and lower sides of the enclosure. Each Unistrut support includes two P1010 channel nuts for attachment. Conduit enters the top and bottom of the panel, secured with typical locknuts, maintaining a mounting height greater than six feet above the finished floor.
PANEL 1-5/8" X 1-5/8" X 12 GAUGE UNISTRUT CHANNELS (TYP.) W/ P1010 CHANNEL NUTS TWO IN EACH UNISTRUT SUPPORT 1-5/8" X 1-5/8" X 12 GAUGE UNISTRUT CHANNELS (TYP.) W/ P1010 CHANNEL NUTS TWO IN EACH UNISTRUT SUPPORT SURFACE MOUNTED PANEL DETAIL LOCKNUT (TYP.) CONDUIT >6'
