An access control panel houses a network controller and door interfaces connected in quantities as required. A twelve-by-twelve-by-four-inch NEMA one power supply connects to a standby one-twenty-volt source and to a six-by-six-by-four-inch NEMA one junction box via a three-quarter-inch conduit. A one-inch conduit connects the junction box to the door interfaces for up to thirty-two total doors. The power supply is provided if required per the door hardware schedule and floor plans.
ACCESS CONTROL PANEL 'ACP 0-1' DOOR INTERFACE (QTY AS REQUIRED) DOOR INTERFACE (QTY AS REQUIRED) NETWORK CONTROLLER 6"X6"X4" NEMA 1 J-BOX 12"X12"X4" NEMA 1 POWER SUPPLY PROVIDE IF REQUIRED. SEE DOOR HARDWARE SCHEDULE AND FLOOR PLANS STANDBY / 120V 3/4" C 1" C TYPICAL DOOR (UP TO 32 TOTAL DOORS)
