Copper ground cables connect to ground rods using exothermic welds in various joint configurations such as tee welds, butt welds, and thru-weld connections. A weld ring attaches to the top of the ground rod, or conductors connect directly to the rod head. Junction welds join multiple cable runs in a single exothermic mold. Weld types include butt welding conductors or executing thru-weld connections.
GROUND ROD GROUND ROD EXOTHERMIC WELD COPPER GROUND CABLE BUTT WELD TEE WELD WELD TO ROD WELD RING TO ROD EITHER BUTT WELD CONDUCTOR OR 'THRU WELD' CONNECTION JUNCTION WELD
