A wide flange beam per plan connects to a column utilizing a typical beam-column connection with four bolts. A hollow structural section beam positioned per plan frames into the assembly below, supported by a 5/8-inch by 9-inch plate centered on the wide flange and hollow structural section beams. A continuous 5/8-inch plate is provided at each side with a hollow structural section beam in front. Five-sixteenths inch fillet welds secure the connection plates and structural members with typical equal spacings.
3" 1" WF BM PER PLAN W/ TYP BEAM-COL CONN HSS BM PER PLAN PL5/8"X9" CENTERED ON WF & HSS BMS 5/8" CONT PL, TYP ES EQ EQ 5/16 5/16 TYP, 3 SIDES 5/16 5/16 5/16 5/16 HSS BM IN FRONT
