A four-inch square box containing a Water Bug or equivalent sensor is attached directly to the floor. A half-inch electrical metallic tubing or liquid-tight conduit extends upward to an eight-by-six-by-four-inch junction box housing a relay and a Water Bug WB-200 controller. The controller assembly connects upward to the fire alarm control panel twenty-four volt direct current power loop. All components including the box, sensor, relay, and controller are furnished and installed by the contractor.
FLOOR ATTACH TO FLOOR 4" SQUARE BOX, WATER BUG (OR EQUIVALENT) SENSOR (W-S-U). BOX AND SENSOR PROVIDED AND INSTALLED BY CONTRACTOR. 1/2"C. EMT OR LIQUID TIGHT RELAY WATER BUG (OR EQUIVALENT) CONTROLLER (WB-200) FURNISHED AND INSTALLED BY CONTRACTOR. 8"X6"X4" J-BOX TO FACP 24V DC POWER LOOP
