An AC power source feeds an incoming line routed through a disconnect enclosure to a variable frequency controller, which then supplies three-phase power to connected motors. Lines are designated as L1, L2, and L3 between each equipment component. A manual motor protector setup provides multi-motor routing from a single variable frequency controller when specified.
AC POWER SOURCE VFC 1 DISCONNECT VFC 1 L1 L2 L3 L1 L2 L3 L1 L2 L3 MOTOR 1 AC POWER SOURCE VFC 1 DISCONNECT ENCLOSURE (1, 2, 3) VFC 1 L1 L2 L3 L1 L2 L3 MOTOR 1 MOTOR 2 MOTOR 3 MMP (1) MMP (2) MMP (3) PROVIDE WITH INTEGRAL DISCONNECT WHERE SCHEDULED OR SPECIFIED L1 L2 L3
