Wireless access point secured via a mounting bracket to a stud and outlet/device backbox positioned above the ceiling line. A horizontal link connects through a secondary pathway to an accessible ceiling or primary pathway. An outlet jack and patch cord complete the internal device wiring.
OUTLET JACK PATCH CORD STUD MOUNTING BRACKET HORIZONTAL LINK OUTLET/DEVICE BACKBOX SECONDARY PATHWAY TO ACCESSIBLE CEILING OR PRIMARY PATHWAY SCALE: NTS 5 WAP - ABOVE CEILING MOUNT
