Each individual conduit is sealed with a conduit plug at the termination point. Two-foot long number four reinforcing bar dowels are placed in the outside concrete envelope at every second conduit from the top. The bare conduit extends twelve inches beyond the duct bank concrete envelope. A red electrical locator ball, furnished by the owner and installed by the contractor, is positioned no deeper than four feet below finished grade directly above the end of the duct bank. The concrete envelope terminates with a forty-five degree slope.
45.00° PLUG EACH INDIVIDUAL CONDUIT WITH CONDUIT PLUGS. RED ELECTRICAL LOCATOR BALL FURNISHED BY OWNER, INSTALLED BY CONTRACTOR. NO DEEPER THAN 4'-0" BELOW FINISHED GRADE, ABOVE END OF DUCT BANK. 2'-0" LONG #4 REBAR (MIN.) DOWELLS PLACED IN OUTSIDE CONCRETE ENVELOPE AT EVERY SECOND CONDUIT FROM THE TOP. DUCT BANK CONCRETE ENVELOPE 12" BARE CONDUIT BOTTOM EXTENDS BEYOND DUCT BANK CONCRETE ENVELOPE. NOTE: NUMBERS & SIZES OF CONDUIT MAY VARY FROM THOSE SHOWN
