Cable trays and J-hooks are suspended above the finished ceiling using threaded rods and Unistrut supports. The Unistrut support is secured with washers and nuts positioned both above and below the channel. The cable tray attaches directly to the Unistrut according to the manufacturer's specifications. The side view indicates vertical spacing dimensions of six inches and three inches for the suspended hardware.
ISOMETRIC VIEW SIDE VIEW CABLE TRAY THREADED ROD (TYP) FINISHED CEILING SECURE CABLE TRAY TO UNISTRUT PER MANUFACTURER'S SPECIFICATIONS WASHER AND NUT ABOVE AND BELOW UNISTRUT (TYP) UNISTRUT SUPPORT (TYP) 6" 3" J-HOOKS (TYP)
