An electrical seal is positioned at the boundary location between an electrical hazardous location and a nonhazardous location area. The seal must be placed at the first conduit joint and within three meters of the wall penetration to prevent the passage of gases or vapors. A luminaire is installed within the hazardous space connected via conduit runs.
LUMINAIRE ELECTRICAL HAZARDOUS LOCATION NONHAZARDOUS LOCATION AREA SEAL AT BOUNDARY LOCATION. SEAL MUST BE AT FIRST CONDUIT JOINT AND WITHIN 3M OF PENETRATION
