An access door assembly featuring perimeter framing studs is secured with hinges along one edge and closed with a recessed handle. The door panel is fastened using recessed 0.5-inch 16-UNC captive pentahead bolts. The assembly measures 59 inches in overall length with interior panel dimensions of 29.25 inches and a width of 24 inches.
FIGURE 3 - ACCESS DOOR DETAIL HINGE RECESSED HANDLE STUD RECESSED .5" 16UNC PENTAHEAD BOLT (CAPTIVE) 59" 29.25" 29.25" 24" 23.5" .25" .25"
