An Evolution Series 4-inch poke-thru electrical device penetrates the floor slab for power distribution. The assembly incorporates a UL-listed fire-rated intumescent material, specifically Hilti FS-One sealant complying with UL-1479, around the core penetration. A power junction box connects below the floor fixture, and top and bottom views show the layout with dimensions of 5 1/2 inches by 5 1/2 inches and an overall depth of 18 9/16 inches. The device is manufactured by Wiremold/Legrand model Evolution 8AT series.
5 1/2" 5 1/2" 18 9/16" TOP BOTTOM #5BLH #575CHA FLOOR UL LISTED FIRE RATED INTUMESCENT MATERIAL-HILTI FS-ONE SEALANT(UL-1479) POWER JUNCTION BOX MANUFACTURER: WIREMOLD/LEGRAND 60 WOODLAWN STREET WEST HARTFORD, CT 06110 PH:800.621.0049 FAX: 860.232.2062 WWW.WIREMOLD.COM MODEL: EVOLUTION 8AT SERIES POKE THRU FOR POWER ONLY - EVOLUTION SERIES 4" POKE THRU DEVICE '4AT'
