A single or duplex receptacle of NEMA 5-20R specification mounts behind a receptacle plate. Nameplates featuring three-sixteenths inch letters are attached to indicate the source panelboard, such as panel RP-11A, and the specific branch circuit number, such as CKT-2.
NAME PLATE 3/16" LETTERS TO INDICATE CIRCUIT NUMBER SINGLE OR DUPLEX RECEPTACLE (NEMA 5-20R) RP-11A NAME PLATE 3/16" LETTERS TO INDICATE PANELBOARD CKT-2 RECEPTACLE PLATE
