Fire Protection · E-386Y9

Equipment

About this detail

This drawing outlines the wiring connections for a duct smoke detector, interfacing with auxiliary equipment, data in and data out loops from previous and next signature devices, and remote signaling components such as an alarm LED or test/relay modules. Terminal blocks on the detector unit connect to auxiliary equipment via terminals fifteen, sixteen, and seventeen, while data loops utilize terminals seven through fourteen. The diagram provides configuration pathways for optional SIGA-LED indicators, SD-TRK relays, or SD-TRM modules.
