The access door assembly measures 59 inches in length by 24 inches in width with a .25-inch frame dimension. It incorporates hinges along one edge, a centrally located recessed handle, and recessed 0.5-inch 16-UNC captive pentahead bolts for secure closure. Framing studs provide structural support around the perimeter of the opening.
FIGURE 3 - ACCESS DOOR DETAIL HINGE RECESSED HANDLE STUD RECESSED .5" 16UNC PENTAHEAD BOLT (CAPTIVE) 59" 29.25" 29.25" 24" 23.5" .25" .25"
