A security camera is mounted to a wall using a four and eleven-sixteenths inch square box connected to a one-inch conduit running back to an accessible ceiling space. The conduit utilizes an insulated bushing and requires additional structural supports. Excess cable is coiled and supported by the building structure with a laminating cable label placed three to four inches from the termination point.
SUPPORT BAR (TYP) 4-11/16" SQUARE BOX LAMINATING CABLE LABEL 3"-4" FROM TERMINATION CABLE COIL SUPPORTED BY BUILDING STRUCTURE (TYP) INSULATED BUSHING (TYP) SUPPORT AS REQ. 1" CND BACK TO ACCESSIBLE CEILING SPACE
