Single gang junction boxes are provided for the card reader and exit station. Conduit routing includes a one-inch conduit from the security control panel, a one-half-inch conduit to the fire alarm system, and a 120 VAC power connection.
SINGLE GANG JUNCTION BOX FOR EXIT STATION SINGLE GANG JUNCTION BOX FOR CARD READER 1"C FROM SECURITY CONTROL PANEL 1/2"C. TO FIRE ALARM 120 VAC
