Electrical · E-25BYV

Parapet Or Side Of Equipment Mounting

Materials

Elements

About this detail

An aluminum air terminal extends ten inches minimum above the item being protected and features either a tapered point or a safety tip with a three-quarter-inch diameter sphere. The solid aluminum rod measuring one-half inch by eighteen or twenty-four inches mounts into an aluminum universal base secured vertically to a parapet or flatly to a roof or equipment surface. A Class 1 aluminum lightning conductor consisting of twenty-four strands of fourteen AWG wires connects through the base assembly. Aluminum cable clips with stainless steel fasteners and aluminum adhesive cable fasteners secure the conductor at maximum intervals of three feet.
