A precast or cast-in-place concrete catch basin and manhole assembly connects to a drainage pipe at a designated inlet elevation. The structure features a 5 inch by 2 inch pipe seat and rounded edges at the inlet openings to facilitate water flow. A manhole shaft conforming to SPPWC 324 extends up to a manhole frame and cover conforming to SPPWC 630 set flush with the street grade. Dimensional callouts indicate an 8 inch dimension, a 14 inch dimension, and a 3 foot 6 inch chamber width.
(15 mm) (350 mm) (75 mm) (125 mm) (610 mm) 5" (125 mm) 5" SEE TABLE 3'-6" (1050 mm) T T 3" (75 mm) 1/2" 8" (200 mm) 3" H 3'-0" (900 mm) 5"x2" (125 mm x 50 mm) PIPE SEAT OF INLETS ROUND EDGES ROUND EDGES STREET GRADE 14" SPPWC 324 SHAFT PER MANHOLE M 24" SPPWC 630 AND COVER PER MANHOLE FRAME POINT APPLIES AT THIS INLET ELEVATION SECTION A-A
