A two-by-four-inch flow opening is centered in the drain tile to prevent debris from entering the inlet structure. Curb inlet caps are installed at each end with a two-foot dimension extending from the back of the curb on both sides.
FLOW 2" x 4" CENTERED IN DRAIN TILE (TO PREVENT DRAIN TILE FROM ENTERING INLET) CURB INLET CAP AT EACH END (2 TYP) FLOW BACK OF CURB 2.00' (BOTH SIDES)
