An eight-inch thick concrete sidewalk features a six-inch high curb with a typical rounded corner and a twelve-inch deep outer edge that steps down four inches. Construction joints are saw-cut one and one-half inches deep typically. The slab bears on a prepared sub-base aggregate layer and abuts a landscape planter area.
