A proposed 10-inch high-density polyethylene SDR 11 water main transitions via mechanical joint adapters to a 10-inch ductile iron pipe 45-degree bend and gate valve. Foster fittings connect the mechanical joint to the bend. The entire fitting assembly is encased in a minimum 4-inch thick flowable fill that extends at least 12 inches past the outermost ductile iron pipe fittings and outside wall of the pipe with a 1-foot minimum clearance.
MJ TO BEND WITH FOSTER FITTINGS 10" DIP MJ 45° BEND 10" GATE VALVE MJXMJ (WHERE OCCURS, SEE PLANS) PROPOSED 10" HDPE SDR 11 WATER MAIN AWWA C906 DIPS HDPE MJ ADAPTER (TYP.) 1' MIN. 1' MIN. 1' MIN. 1' MIN. NOTE: FLOWABLE FILL SHALL EXTEND A MINIMUM OF 12" PAST OUTER MOST DIP FITTING AND A MINIMUM OF 12" PAST OUTSIDE WALL OF PIPE. HDPE MJ ADAPTER (TYP.) FLOWABLE FILL (4" THICK MIN.)
