A twelve-inch thick concrete pavement abuts an HMA Superpave asphalt wearing course separated by an expansion joint. The concrete slab features a thickened edge dropping twelve inches and a construction joint forming a ribbon pattern twenty-four inches from the transition. Beneath the paving layers, a three-quarter-inch crushed aggregate base course compacted to ninety-five percent ASTM D-1557 sits over a six-inch diameter pit run layer. Unverified subgrade fill beneath the assemblies is removed and re-compacted to depths specified by the geotechnical engineer.
3/4" CRUSHED AGGREGATE BASE COMPACTION SHALL MEET GEOTECH RECOMMENDATIONS (95% ASTM D-1557); SECTION PER DETAIL 1 THIS SHEET CONSTRUCTION JOINT TO CREATE "RIBBON" REMOVE AND RE-COMPACT UNVERIFIED FILL TO DEPTHS AS REQUIRED BY GEOTECHNICAL ENGINEER (PER REPORT) 6"-Ø PIT RUN; SECTION PER DETAIL 1 THIS SHEET 24" 12" 12" THICKENED CONCRETE PAVEMENT (SEE PAVEMENT SECTION REQUIREMENTS) CONCRETE TO ASPHALT CONNECTION NOT TO SCALE 7 C102 EXPANSION JOINT HMA SUPERPAVE PG64-28 SP2 WITH 12 -INCH NOMINAL MAXIMUM SIZE AGGREGATE; SECTION PER DETAIL 1 THIS SHEET
