A temporary silt fence is installed along contours to control sediment runoff. Wooden or steel fence posts are positioned on the downstream side of the fence at a maximum spacing of ten feet on center. Mirafi filter fabric is extended down into an approximate six-inch by six-inch trench and backfilled with free draining granular material. The fabric flap is embedded below the backfill to prevent sediment bypass. An optional sidewalk and curb and gutter appear adjacent to the installation area.
RUNOFF 1 2 MAX RUNOFF DIRECTION 2'-0" 6" 12" MIN. SIDEWALK IF ANY CURB AND GUTTER IF ANY UNDISTURBED GROUND WOODEN OR STEEL FENCE POSTS @ 10.0' O.C. MAX. MIRAFI FILTER FABRIC GRANULAR BACKFILL, SEE NOTE 3 APPROX. 6"x6" TRENCH EMBED FABRIC BELOW BACKFILL 1. EXCAVATE 6"x6" TRENCH ALONG LIMITS OF DISTURBANCE AS SHOWN ON CONSTRUCTION DRAWINGS. 2. POSTS SHALL BE POSITIONED ON DOWNSTREAM SIDE OF FENCE. 3. LAY TOE-IN FABRIC FLAP IN BOTTOM OF TRENCH. BACKFILL TRENCH WITH FREE DRAINING GRANULAR MATERIAL. COMPACT TRENCH TO SATISFACTION OF THE ENGINEER OF RECORD. 4. SILT FENCE GEOTEXTILE SHALL MEET AASHTO M288-92 REQUIREMENTS. 5. REMOVE & DISPOSE OF SEDIMENT WHEN ACCUMULATION IS 50% OF EXPOSED FENCE HEIGHT. 6. 10' MAX. SPACING BETWEEN STAKES. 7. SILT FENCES SHALL BE INSTALLED ALONG CONTOURS, NOT UP AND DOWN SLOPES, WITH 10' OVERLAP AT BREAKS. NOTES:
