C-XTM5B — Cupola Detail

Civil · C-XTM5B

Cupola Detail

Scale: SCALE: 3" = 1'-0"
Units: imperial
Sheet: C5
Discipline: Civil

Materials

Composite Membrane / Roofing Metal (misc.)Stainless Steel Steel Stone Timber / Wood

Elements

Drainage Facades / Cladding Roofs Trusses Waterproofing / Flashing

Text on the drawing

5/16" CEMENT FIBER PANEL COPPER SLATING NAIL SLATE SHINGLES WOOD BLOCK; RIP TO SIZE STAINLESS STEEL METAL FLASHING WITH DRIP EDGE 1/2" TREATED PLYWOOD PLYWOOD ROOF SHEATHING SHEET WATER BARRIER 5/16" CEMENT FIBER PANEL WOOD TRUSS WOOD STUD FRAMING WEEP HOLE AT 16" O.C. ASPHAULT MEMBRANE
