A roof downspout terminates at a rock splash pad composed of twelve inches of two to three inch stream bed cobbles extending from the building face to the drainage swale. A waterproof membrane with a felt liner is attached to the exterior building wall and extends five feet minimum from the building face. A footing drain is installed per plan adjacent to the concrete footing below the drainage layer.
FOOTING DRAIN PER PLAN DOWNSPOUT - SEE ARCHITECTURAL DETAILS AND SPECIFICATIONS FOR ABOVE GRADE FITTINGS, INCLUDING 90° ELBOW. SPLASH DOWNSPOUT ONTO ROCK PAD ROCK SPLASH PAD PER PLAN, 12-INCHES OF 2" TO 3" STREAM BED COBBLES EXTENDING FROM BUILDING DOWNSPOUT TO BOTTOM OF DRAINAGE SWALE. BUILDING PER ARCHITECTURAL PLANS 4 C604 WATERPROOF MEMBRANE W/ FELT LINER. LINER EXTENDS 5 FEET MINIMUM FROM BUILDING FACE ATTATCH LINER TO BUILDING PER ARCHITECTURAL DETAILS
