An 0.125-inch aluminum metal panel connects to the jamb framing assembly of the OPG1900 series system. G1 gaskets seal the panel edges within the aluminum extrusion channels. Fasteners secure the framing components at the vertical opening interface.
G1 G1 .125" ALUM. METAL PANEL Arch Ref: SYSTEM: AT METAL PANEL JAMB DETAIL 1a N/A OPG1900 SERIES
