A concrete pavement expansion joint features a field molded sealant over a bond breaker tape or backer rod and a non-extruding preformed compressible material. The joint reservoir has a minimum width W of 3/4 inch and a recess depth of 1/8 plus or minus 1/16 inch below the concrete pavement surface. Sealant depth D is maintained at 0.5W for silicone or 1.5W for hot-poured sealants per manufacturer recommendations. Backer rod material minimum diameter and bond breaker tape minimum width equal W plus 1/8 inch. Sawcut depth of the joint reservoir must be coordinated with the sealant manufacturer.
3/4" MIN "W" 1/8"±1/16" BOND BREAKER TAPE OR BACKER ROD MATERIAL (SEE NOTE 3) CONCRETE PAVEMENT SURFACE NON-EXTRUDING PREFORMED COMPRESSIBLE MATERIAL SEALANT DEPTH D= 0.5W FOR SILICONE; 1-1.5W FOR HOT POURED PER SEALANT (SEE NOTE 2) NOTES: 1. COORDINATE SAWCUT DEPTH OF JOINT RESERVOIR WITH SEALANT MANUFACTURER'S RECOMMENDATIONS. 2. WHEN BACKER ROD MATERIAL IS USED, DIMENSION IS FROM TOP OF FIELD MOLDED SEALANT TO TOP OF BACKER ROD MATERIAL. 3. BACKER ROD MATERIAL MINIMUM DIAMETER EQUAL TO W+1/8" BOND BREAKER TAPE MINIMUM WIDTH EQUAL TO W+1/8". FIELD MOLDED SEALANT
