Concrete reinforcing bar layout at a retaining wall return corner of type D. The wall stem incorporates two-way reinforcing with number five bars spaced at sixteen inches on center. The corner return features number five bars totaling three and number five bars totaling four, with specified bar hooks and lap lengths. Clear dimensions indicate a one-foot offset and two-foot spacing increments for the wall configuration.
