Twelve-inch solid white stripes form a solid border and diagonal cross stripes in a pedestrian crosswalk marking layout. The crosswalk has a typical width of eight feet and a typical stripe spacing of four feet. The front edge of the crosswalk is set two feet back from the front face of the curb. All dimensions are typical for standard site paving and pedestrian access routing.
8'-0" (TYP) 4'-0" (TYP) 2'-0" TO FRONT OF CURB 12" SOLID WHITE STRIPE BORDER AND CROSS STRIPE
