A monolithic concrete curb and sidewalk rests on a six-inch untreated base course and an eighteen-inch compacted subgrade compacted to ninety-five percent per ASTM D-1557. The four-inch concrete sidewalk incorporates two continuous number four reinforcing bars. The outer curb edge features a six-inch vertical height adjacent to the finish paved grade and a three-quarter-inch radius at the top corner.
18" 6" COMPACTED SUBGRADE 8" THICK TO 95% PER ASTM D-1557 6" UNTREATED BASE COURSE (SEE NOTE 1 APWA PLAN NO. 205) FINISH PAVED GRADE 6" 3/4" RADIUS 4" CONC. SIDEWALK 4" (2) #4 BARS CONT.
