Four fire system dual micro switches are located in the Automan and shown in the cocked position representing a system ready state. Voltage free normally open and normally closed contacts provide interconnection to the building alarm system. Individual micro switches MS1 through MS4 connect to the system wiring.
TYPICAL FIRE SYSTEM WIRING DIAGRAM (ANSUL SHOWN) (4) FIRE SYSTEM DUAL MICRO SWITCHES LOCATED IN AUTOMAN. SWITCHES SHOWN IN COCKED POSITION (SYSTEM READY) VOLTAGE FREE N/O AND N/C CONTACTS FOR INTERCONNECTION TO THE BUILDING ALARM SYSTEM N/O N/C N/C N/O MS2 MS1 N/O N/C MS3 N/O N/C MS4
