An accessible parking access aisle layout is defined by 150 millimeter wide white traffic paint stripes using lead free paint. The overall stall dimensions measure 1525 millimeters wide by 5640 millimeters long, with 150 millimeter spacing and border offsets. A 300 millimeter diagonal hatch stripe spacing is specified across the marking area.
150 VAN ACCESSIBLE PARKING MARKING 150 150 1525 300 150 WHITE TRAFFIC PAINT FOR ACCESS AISLE (LEAD FREE PAINT) 5640
